What we can do ? different country different requirement all we can offer.
Mid-voltage ( kV) | 3.6~35kv (E.g. 35,33,24,22,20,18,15.75,13.8,13.2,12,11,10.5,10,7.2,6.6,6.3,6 etc.) |
To Low voltage ( V) | 100-660V (E.g. 100,110,115,120,127,208,200,220,230,240,346,380,400,410,415,440,480,660 etc.) |
Frequency (HZ) | 50Hz or 60Hz |
S13-M.RL 6~10kv double winding without excitation regulator fully enclosed oil immersed distribution transformer
1、 Overview
S13-M.RL-80 ~ 1600 / 10 fully sealed oil diffuse transformer is suitable for power systems with AC 50Hz and rated working voltage of 10kV and below. It is used as distribution transformer in petroleum, metallurgy, chemical industry, textile, light industry and other enterprises and places with large dust.
2、 Model and description
S13 MRL口 /口
口 - high voltage side electrical grade (kV)
口- rated capacity (kVA)
L-solid
R-coil core
M-fully sealed
13 - Design serial number
S-three phase
3、 Use environment
◆ the installation height shall not exceed 1000m above sea level;
◆ ambient temperature: - 40℃ ~ + 40℃
4、 Technical parameters
Rated capacity (kVA) | Voltage combination | Connect the group logo number | No load loss (kW) | Load loss (kW) | No load current (%) | Short circuit impedance (%) | Weight (kg) | |||
HV(kA) | High pressure connection range | LV(kA) | Oil weight | Gross weight | ||||||
30 | 6 6.3 6.6 10 10.5 11 | 士5%±2x2.5% | 0.4 | Yyn0 Dyn11 | 4 | 110 | 360 | |||
50 | 115 | 425 | ||||||||
63 | 130 | 1310/1250 | 0.22 | 160 | 530 | |||||
80 | 150 | 1580/1500 | 0.21 | 165 | 555 | |||||
100 | 170 | 1890/1800 | 0.20 | 170 | 760 | |||||
125 | 200 | 2310/2200 | 0.19 | 200 | 850 | |||||
160 | 240 | 2730/2600 | 0.18 | 230 | 990 | |||||
200 | 290 | 3200/3050 | 0.17 | 255 | 1125 | |||||
250 | 340 | 3830/3650 | 0.16 | 305 | 1350 | |||||
315 | 410 | 4520/4300 | 0.16 | 380 | 1620 | |||||
400 | 480 | 5410/5150 | 0.16 | 400 | 1950 | |||||
500 | 570 | 6200 | 0.15 | 4.5 | 420 | 2200 | ||||
630 | 700 | 7500 | 0.15 | 530 | 2420 | |||||
800 | 830 | 10300 | 0.14 | 660 | 2960 | |||||
1000 | 970 | 12000 | 0.13 | 660 | 3140 | |||||
1250 | 1170 | 14500 | 0.12 | 780 | 3760 | |||||
1600 | 1200 | 5520 | ||||||||
2000 | 1500 | 6050 | ||||||||
2500 | 1300 | 5650 | ||||||||
